Machine de remplissage rotatoire de pesage pour l'huile de lubrifiants

Accueil / Machines de remplissage / Machine de remplissage rotatoire de pesage pour l'huile de lubrifiants

weighing rotary filling machine for lubricants oil

Principales caractéristiques

This machine is the latest generation of rotary weighing filling and capping integrated models, high automation, high production capacity, the filling is controlled by METTLER - TOLEDO weighing sensors and feedback instrument control. Suitable for edible oil, spices, oil and other industries bottled packaging.

1. This machine adopts PLC, touch screen control panel, weighing instrument to adjust and control. It is convenient to adjust.

2. Each filling head has the weigh and feedback system .each filling head can be regulated and micro adjusted.

3. The whole machine gets GMP standard. It is easy to disassemble clean and maintain, and the parts which contact with the filling products are made of high quality stainless steel. The whole machine is safe . Environmental, sanitary. It can adapt to various kinds of working places.

4. capping head Department uses located way. And set the direction of photoelectric sensors at the barrel-inlet, No barrel no capping.

paramètres techniques


Dimensions3000mm (L) ×2200mm (W) × 2450mm (H)
Filling/ capping head24 filling heads /8 capping heads
Suitable bottleDiameter:: Φ50mm~ Φ180mm height:120mm~350mm
Packing specification1L-5L
Production capacity (1L)6000B/H (for 1L)  3000B/H (for 5L)
Measurement error±2g for 1L
source de courant380V;50/60HZ
host power 6.5KW
Arrivée d'air0.55MPa~0.65MPa clean and stable source of gas supply with gas

Détails rapides


Type: machine de remplissage
Condition: Nouveau
Application: boisson, produit chimique, nourriture, médical
Type de conditionnement: Étui
Matériel d'emballage: bois
Grade automatique: automatique
Type de moteur: électrique
Tension: 220V / 50Hz
Puissance: 4.5KW
Lieu d'origine: Shanghai, Chine (continentale)
Nom de marque: NPACK
Dimension(L*W*H): 3000mm (L) x 2200mm (W) x 2450mm (H)
Poids: 2500kg
Certification: CE
Service après-vente fourni: Ingénieurs disponibles pour entretenir des machines à l'étranger
Matériel: SS304
Speed: ≤3000bottles/hour for 4L
Filling range: 1L-5L
Filling heads: 24 heads (or customized)
capping head: 8 heads (or customized)
